NV 26-28-32
VERTICAL WINDLASSES
Vertical Windlass model NV-26, NV-28, NV-32 All in Stainless Steel AISI 316. Available with different drives and recommended for vessels up to 90m. All models accommodate stud link chain. Available in 230V, 400V or hydraulic drive.
Hydraulic
SPECIFICATIONS
| ELECTRIC MOTOR | 11000W | 15000W | 22000W | HY |
| MOTOR SUPPLY VOLTAGE | 230V/400V | 230V/400V | 230V/400V | N/A |
| MAXIMUM PULL | 9200 Kg | 13800 Kg | 18800 Kg | 9425 Kg |
| LIFT WORKING LOAD | 4600 Kg | 6950 Kg | 9425 Kg | 9425 Kg |
| LINE SPEED | 13 mt/min | 12 mt/min | 12 mt/min | 12 mt/min |
11000
| A | 550 |
| B | 440 |
| C | 320 |
| D | 535 |
| E | MIN240 |
| F | 492 |
| G | 830 |
15000
| A | 600 |
| B | 470 |
| C | 340 |
| D | 662 |
| E | CUSTOM |
| F | 470 |
| G | 1080 |
HY
| A | 600 |
| B | 470 |
| C | 340 |
| D | 662 |
| E | CUSTOM |
| F | 540 |
| G | 730 |
All sizes are in mm
