STAR
VERTICAL WINDLASSES
STAR is a stainless steel AISI 316 vertical windlass. Available in high or low profile, with different drives and recommended for boats up to 19m. STAR can use chains from 10mm to 13mm. Available in 12V, 24V, 230V, 400V or hydraulic drive.
Hydraulic
SPECIFICATIONS
| ELECTRIC MOTOR | 1500W | 1500W | 1700W | 1700W | 2000W | HY | 2000W |
| MOTOR SUPPLY VOLTAGE | 12V | 24V | 12V | 24V | 24V | N/A | 230V/400V |
| MAXIMUM PULL | 1250 Kg | 1290 Kg | 1650 Kg | 1700 Kg | 1750 Kg | 380 Kg | 1700 Kg |
| LIFT WORKING LOAD | 170 Kg | 180 Kg | 240 Kg | 250 Kg | 270 Kg | 380 Kg | 250 Kg |
| LINE SPEED | 12 mt/min | 12 mt/min | 12 mt/min | 12 mt/min | 12 mt/min | 12 mt/min | 12 mt/min |
| CURRENT ABSORPTION | 130 A | 70 A | 138 A | 75 A | 100 A | N/A | N/A |
| WEIGHT (WITHOUT CAPSTAN) | <>30 to 35 Kg | ||||||
| WEIGHT (WITH CAPSTAN) | <>30 to 35 Kg | ||||||
1500
| A | 150 |
| B | 102 |
| C | 212 |
| D | 37/62 |
| E | 150 |
| F | 250 |
| G | 112 |
| H | 62 |
| I | 114 |
1700
| A | 150 |
| B | 102 |
| C | 212 |
| D | 37/62 |
| E | 165 |
| F | 330 |
| G | 112 |
| H | 85 |
| I | 125 |
2000-DC
| A | 150 |
| B | 102 |
| C | 212 |
| D | 37/62 |
| E | 165 |
| F | 335 |
| G | 112 |
| H | 85 |
| I | 125 |
HY
| A | 150 |
| B | 102 |
| C | 212 |
| D | 37/62 |
| E | 165 |
| F | 227 |
| G | 112 |
| H | 85 |
| I | 170 |
2000-AC
| A | 150 |
| B | 102 |
| C | 212 |
| D | 37/62 |
| E | 210 |
| F | 350 |
| G | 112 |
| H | 85 |
| I | 165 |
All sizes are in mm
