Premium self-launching anchors designed for maximum holding power and easy recovery.
Self-launching design
Self-aligning to bow roller
Maximum holding power
Instantly resets to attack position
316 Stainless Steel
Lifetime warranty
Proudly manufactured
in Türkiye.
Installed on premium
vessels.
Built from 316 stainless
steel.
Against manufacturing
defects.
The Ultra Anchor is a new generation anchor that sets the standard in anchoring performance and reliability.
With its unique features and superior design, the Ultra buries itself deep into the seabed and will never release even under the most unfavourable weather and underwater conditions.
Hand made from 316 stainless steel and hand polished, every Ultra Anchor is designed for excellence.
Even under the most extreme load the shanks' reinforced eye will not bend, break or fail.
The anchor weight is stamped into the shank & identifies the anchor size in both kgs and lbs.
Enables weight to be concentrated on anchor tip.
Anchor cannot lie on its spine & recovers instantly to the attack position. Loads correctly into the bow roller.
Often chain can foul around the shank of the anchor, resulting in the anchor nt able to set. The clever design feature of the non chain-foul bar ensures chain simply cannot wrap around the shank & provides the ability to attatch a trip line.
Once you begin to recover the anchor from the seafloor, it pivots itself on the flat section & begin to release (boat should be directly over anchor).
The anchor does not release in a changing wind or tide, it performs a complete 180 degree rotation (while still buried) on its own length and holds firm. The side wing plates assist the anchor to perform this procedure & also act to stabilize the anchor as it penetrates the sea floor.
Lead is inserted into the anchor tip, achieving optimal weight distribution & ensuring anchor penetrates unfavourable bottom conditions.
Importantly, the anchor tip is shaped downwards, ensuring an instatnt set in the sea floor.
The concave base/fluke has the appearance of a spade of shovel, & has extreme holding power with a greater surface area than conventional style anchors. The result is a more secure, higher holding power anchor that will not release.
Self-launching off your bow roller
Unique self-righting features
Always lands in the attack position
Easily recoverable from the bottom
Instantly buries deep and holds firm
Self-aligning into your bow roller
Does not release in changing wind or tide
Stunning 316 stainless steel anchor
| RECOMMENDED ULTRA ANCHOR WEIGHT |
SAIL BOAT | POWER BOAT | MULTIHULL | SUGGESTED CHAIN SIZE |
RECOMMENDED SWIVEL |
|||||
|---|---|---|---|---|---|---|---|---|---|---|
|
⛵ MONO HULL |
🚤 HIGH PROFILE |
🚤 LOW PROFILE |
⛵ SAIL |
🚤 POWER |
||||||
| Boat Weight |
Boat Length |
Boat Weight |
Boat Length |
Boat Length |
Boat Weight |
Boat Length |
Boat Length |
|||
| (kg) | (ton) | (m) | (ton) | (m) | (m) | (ton) | (m) | (m) | mm | # |
| UA 5 | 1 | 5 | 1,1 | 5,2 | 5,7 | 0,7 | 4,3 | 4,6 | 5 | UFS 6 - 12 |
| UA 8 | 2 | 7 | 2,2 | 7,2 | 7,9 | 1,4 | 6,1 | 6,4 | 6 | UFS 6 - 12 |
| UA 12 | 3,8 | 9 | 4,2 | 9,3 | 10,2 | 2,7 | 7,8 | 8,2 | 6 | UFS 6 - 12 |
| UA 16 | 6,3 | 10,8 | 6,9 | 11,1 | 12,2 | 4,5 | 9,3 | 9,8 | 6 - 8 | UFS 8 - 21 |
| UA 21 | 10,2 | 12,6 | 11,2 | 13 | 14,3 | 7,3 | 10,9 | 11,5 | 8 | UFS 8 - 21 |
| UA 27 | 14,6 | 14,3 | 16 | 14,7 | 16,2 | 10,5 | 12,4 | 13 | 8 - 10 | UFS 10 - 35 |
| UA 35 | 21,5 | 16 | 23,5 | 16,5 | 18,2 | 15,6 | 13,8 | 14,6 | 10 | UFS 10 - 35 |
| UA 45 | 30 | 17,8 | 32,9 | 18,3 | 20,1 | 21,6 | 15,4 | 16,2 | 10 - 12 | UFS 13 - 60 |
| UA 60 | 43 | 20 | 47,1 | 20,6 | 22,7 | 31 | 17,3 | 18,2 | 12 - 13 | UFS 13 60 |
| UA 60 | 174 | 30,4 | 191 | 31,3 | 34,4 | 125 | 26,3 | 27,7 | 16 | UFS 20 - 200 |
| UA 80 | 63 | 22,3 | 69 | 23 | 25,3 | 45,4 | 19,3 | 20,3 | 13 | UFS 16 110 |
| UA 100 | 85 | 24,5 | 93 | 25,2 | 27,7 | 61 | 21,2 | 22,3 | 14 | UFS 16- 110 |
| UA 130 | 123 | 27,4 | 135 | 28,2 | 31 | 89 | 23,7 | 25 | 14 - 16 | UFS 20 - 200 |
| UA 200 | 262 | 34,4 | 287 | 35,4 | 39 | 190 | 29,8 | 31,3 | 18 | UFS 20 - 200 |
| UA 250 | 400 | 39,2 | 438 | 40,4 | 44,4 | 290 | 33,9 | 35,7 | 19 | UFS 26 - 360 |
| UA 300 | 550 -1 | 44 | 600 | 45,3 | 49,8 | 400 | 38,1 | 40 | 20 | UFS 26 - 360 |
| UA 360 | 760 | 50 | 830 | 51,5 | 56,7 | 550 | 43,3 | 45,5 | 21 | UFS 26 - 360 |
Download the full brochure for detailed specifications and installation guide.
Australia’s Marine Chain Specialists
COMMENTS
They are not suitable for vertical or straight hawse holes.
-For lighter boats, choose 1 size bigger.
-For heavier boats, choose 1 smaller.
WARRANTY
CAUTION
